Couplings
Boston Gear XFCA12 Poly Insert
Boston Gear Polyurethane Spider Insert for Boston Gear FC12 and SSFC12Key Features
- Size - Jaw Couplings FC12
- Material - Spiders Synthetic Rubber
- Rated Torque 125 in-lb
- Max. RPM 3,600 RPM
- HP Rating @ 100 RPM 0.19
Boston Gear XFCA15 Polyurethane Shaft Coupling Insert
Boston Gear Polyurethane Spider Insert for Boston Gear FC15 and SSFC15
BOSTON GEAR Polyurethane Spider Insert: FC15, 250 in-lb Rated Torque, 3,600 RPM Max., -32° to 200°F
Boston Gear XFCA20 Polyurethane Spider Insert
MFR DESCRIPTION XFCA20 NON METAL INSERTS 08054
- Oil-Resistant Synthetic Rubber is recommended where quietness is desired, particularly at motor speeds
- Polyurethane is recommended where moderate to heavy shock loads are encountered
- Oil-Impregnated Bost-Bronze is recommended for high torque loads, particularly at slower speeds
Boston Gear XFCA25 Polyurethane Shaft Coupling Insert
- Size - Jaw Couplings: FC25
- Material - Spiders: Polyurethane
- Rated Torque: 845 in-lb
- Max. RPM: 3,600 RPM
- HP Rating @ 100 RPM: 1.20
- Temp. Range: -32 Degrees to 200 Degrees F
- HP Rating @ 1750 RPM: 19.3 hp
Boston Gear XFCA30 Polyurethane Shaft Coupling Insert
Boston Gear Polyurethane Spider insert - Boston Gear FC30 and SSFC30
- Size - Jaw Couplings: FC30
- Material - Spiders: Polyurethane
- Rated Torque: 1,500 in-lb
- Max. RPM: 3,600 RPM
- HP Rating @ 100 RPM: 2.20
- Temp. Range: -32 Degrees to 200 Degrees F
- Serviceable Temp. Range (F): -32 to 200
Boston Gear XFCA38 Polyurethane Shaft Coupling Insert
Boston Gear Polyurethane Spider Insert for Boston Gear FC38 and SSFC38- Size - Jaw Couplings: FC38
- Material - Spiders: Polyurethane
- Rated Torque: 3,000 in-lb
- Max. RPM: 1,800 RPM
- HP Rating @ 100 RPM: 4.30
- Temp. Range: -32 Degrees to 200 Degrees F
- HP Rating @ 1150 RPM: 45.8 hp
Boston Gear XFCA45 Polyurethane Spider Insert
Boston Gear Polyurethane spider insert Boston Gear FC45 and SSFC45- Size - Jaw Couplings: FC45
- Material - Spiders: Polyurethane
- Rated Torque: 5,250 in-lb
- Max. RPM: 1,800 RPM
- HP Rating @ 100 RPM: 7.50
- Temp. Range: -32 Degrees to 200 Degrees F
- HP Rating @ 300 RPM: 22.4
Boston Gear XFCBB12 BOST-BRONZ Shaft Coupling Insert
Boston Gear Bost-Bronz spider insert for Boston Gear FC12 and SSFC12
PRODUCT DETAILS
- Size FC12 Coupling Insert
- Bronze
FEATURES
- Recommended for high torque loads, particularly at slower speeds
- Mfr # 08064
Boston Gear XFCBB15 Bost-Bronz Coupling Insert
Boston Gear Bost-Bronz spider insert for Boston Gear FC15 and SSFC15 Mfr # XFCBB15 BRONZE INSERTS 08066
Boston Gear XFCBB20 Bost-Bronz Coupling Insert
OVERVIEW
MFR DESCRIPTION
XFCBB20 BRONZE INSERTS 08068
- Oil-Resistant Synthetic Rubber is recommended where quietness is desired, particularly at motor speeds
- Polyurethane is recommended where moderate to heavy shock loads are encountered
- Oil-Impregnated Bost-Bronze is recommended for high torque loads, particularly at slower speeds
Boston Gear XFCBB30 BOST-BRONZ Shaft Coupling Insert
Boston Gear Bost-Bronz spider insert for Boston Gear FC30 and SSFC30
MFR # BRONZE INSERTS 08072
BOSTON GEAR Oil Impregnated Spider Insert: FC30, 3,200 in-lb Rated Torque, 690 RPM Max., Bronze
